Interfold 50F

Finish:

Interfold 50F is a robust, stainless steel-based, top hung folding system designed specifically for heavy-duty interior timber doors, without a floor-mounted guide channel. This exceptional hardware system confidently supports doors of equal width up to an impressive 50kg.

Available as simple to use kits, with 4 stylish finish options available, it offers a perfect fit for every style.

Top hung folding door hardware system for timber doors of equal width, weighing up to 50kg.

For residential and commercial applications where no floor channel is required
Rebated frame allows for additional seals if required
316 marine grade stainless steel hangers with nylon outer tyres and aluminium track provide a smooth quiet operation
A maximum of 4 doors can be pivoted to the left or right of an opening (8 in total with 4 panels folding to each side)
For timber systems with all doors of equal width

Track System

Maximum Number of Panels

Maximum Panel Width

Maximum Panel

Panel Thickness

Maximum Panel Weight

Door Material

Application

Interfold 50F

838mm

2200mm

35-56mm

50kg

Timber

Internal

Interfold 50F door hardware kits:

Product Code	Description	Track Length	Finish	BWS1F-100H Adjustable Pivot Set	BWS2F-50SH Universal End Hanger Set	BWS4F-50SH Intermediate Hanger Set	BW7-100H Hinge Offset Handle Set	BW3-100H Straight Hinge Handle Set	456R Flush Bolts
INT50F-2P	Interfold 50F 2 Door Kit	2500mm x 1	SS BLK PB PS	1	1	0	0	1	2
INT50F-2+1P	Interfold 50F 2+1 Door Kit	3000mm x 1		2	1	0	0	1	2
INT50F-2+2P	Interfold 50F 2+2 Door Kit	3500mm x 1		2	2	0	0	2	4
INT50F-3P	Interfold 50F 3 Door Kit	3000mm x 1		1	0	1	1	0	3
INT50F-3+1P	Interfold 50F 3+1 Door Kit	3500mm x 1		2	0	1	1	0	5
INT50F-3+2P	Interfold 50F 3+2 Door Kit	2000mm x 1 2500mm x 1		2	1	1	1	1	5
INT50F-3+3P	Interfold 50F 3+3 Door Kit	2500mm x 1 3000mm x 1		2	0	2	2	0	8
INT50F-4P	Interfold 50F 4 Door Kit	3500mm x 1		1	1	1	2	0	4
