Brio 456R is designed for both inward and outward opening external folding doors, French doors and sliding door applications. Its low-profile design reduces rebate depth while maintaining the strength of the timber stile, and modern round-cut top allows for quick machining, enabling the rebate to be machined in a single router operation, saving valuable installation time.
Available in non-locking and locking where extra security is required.
Round-cut top lockable flush bolt
Minimum Door Thickness | Flush Bolt Length | Throw Length | Finish | Security | Application |
35mm | 190mm 450mm 600mm 1000mm | 20mm | SS PS PB BLK | Locking and non-locking | Folding doors French doors Sliding doors |
| Code | Description | Finish |
| 456R | Flush bolt straight non locking 190mm | SS - Satin Stainless PS - Polished Stainless PB - Polished Brass BLK - Black |
| 456RE | Flush bolt straight locking 190mm | |
| 456RN | Flush bolt Offset non locking 190mm | |
| 456REN | Flush bolt Offset locking 190mm | |
| 456RI | Flush floor non locking 190mm | |
| 456REI | Flush floor locking 190mm | |
| 456RL | Straight non locking 450mm | |
| 456RLE | Straight locking 450mm | |
| 456RLN | Offset non locking 450mm | |
| 456RLX | Straight non locking 600mm | |
| 456RLNX | Offset non locking 600mm |
Brio, part of the Allegion family of brands
